KEF Ci200TRb In-Ceiling Subwoofer

In-Store Pickup Only
KEFSKU: Ci200TRb

Please contact us for pricing and availability at 315-458-5000 or email us at info@teamiu.com.

Description

Features KEF’s patented Uni-Q driver array

Boasting a formidable 200mm (8in.) subwoofer incarnation of our ultra-thin T Series woofer driver, the Ci200TRb opens up new possibilities for enjoying KEF’s uncompromised sound quality where installation space is at a premium.

Ci200TRb

Boasting a formidable 200mm (8in.) subwoofer incarnation of our ultra-thin T Series woofer driver, the Ci200TRb opens up new possibilities for enjoying KEF’s uncompromised sound quality where installation space is at a premium.

Requiring less than 59mm (2 3/8 in.) of mounting depth, the Ci200TRb fits snugly in very narrow ceiling or wall spaces and is therefore specified for demanding applications such as today’s luxury high-rise apartments or your music system.

When used in passive mode, the Ci200TRb adds impressive depth of bass when matched with our Ci160TR round or Ci160TS square speakers. In active mode, powered by KEF’s KASA500 System Amplifier, the Ci200TRb delivers thunderous output expected from a subwoofer in today’s dynamic home theaters.



Key Features

  • <59mm (2 3/8in.) mounting depth allows fitment to very restricted cavities
  • Ultra-slim 200mm (8in.) subwoofer unit with excellent bass extension
  • Paintable Ultra-Thin Bezel (UTB) and magnetic grille to blend unobtrusively with décor
  • Fast, versatile installation on virtually any surface via dogleg
  • Can be used as mono or stereo subwoofer
  • Can be used in passive mode with internal crossover or active mode with KEF’s KASA500 System Amplifier


SPECIFICATIONS

NOMINAL IMPEDANCE

2 x 8 Ohm - Stereo Mode
16 Ohm - Mono Mode

SENSITIVITY

87dB (2.83V/ 1m)

FREQUENCY RESPONSE

42Hz-120Hz - Passive
32Hz-120Hz - With Kasa500

DRIVE UNITS

LF: 200mm (8 in.)

RECOMMENDED AMPLIFIER POWER

10-125W - Passive
KASA500 - With Kasa500

PRODUCT EXTERNAL DIMENSION (H X W X D)

Diamater: 290 mm (11.42 in.)
Depth: 63mm (2.48 in.)

CUT-OUT DIMENSIONS (H X W)

240mm (9.45 in.)

MOUNTING THICKNESS

Ceiling Thickness (Maximum): 26mm (1.03 in.)
Ceiling Thickness (Minimum): 4mm (0.16 in.)

MOUNTING DEPTH FROM SURFACE

59mm (2.32 in.)

OPTIONAL ROUGH IN FRAME

RIF200R

OPTIONAL REAR ENCLOSURE

RNC200R

NET WEIGHT

1.7kg (3.75 lbs)

UNIT MEASUREMENT

Piece
